Deep Cycle 100Ah 200Ah 300Ah 400Ah 12V 24V Lithium Iron Phosphate Rechargeable Battery
Specification
| Nominal voltage | 12.8v | 25.6v | 51.2v |
| Nominal capacity | 200ah | 200ah | 200ah |
| Battery type | grade A 3.2V LifePO4 Prismatic Lithium iron phosphate battery cell 4S | grade A 3.2V LifePO4 Prismatic Lithium iron phosphate battery cell 8S | grade A 3.2V LifePO4 Prismatic Lithium iron phosphate battery cell 16S |
| Charge Voltage | 14.6V±0.2V | 29.2V±0.2V | 58.4V±0.2V |
| Discharge Cut-off Voltage | 10V | 20V | 40V |
| Standard charging current (A) | 50A |
| BMS function | Overcharge, overdischarge, overcurrent, short circuit, etc. |
| Nominal internal resistance | Single cell ≤2mΩ |
| Continuous discharge current | 250A |
| Peak current | 240A (<3s) |
| charging temperature | 0℃ to 55℃ (32F to 131F) @60±25% Relative Humidity |
| discharge temperature | -20℃ to 60℃ (-4F to 140F) @60±25% Relative Humidity |
| Storage Temperature | -20℃ to 45℃ (-4F to 113F) @60±25% Relative Humidity |
| Life cycle | It is 2000 times at 85% dose, 5000 times at 65% dose, and 8000 times at 40% dose. |
| Net weight | 22kg | 43kg | 90kg |
| Battery display | The conventional ABS housing has a display screen. Others can be customized |
| Battery size | ABS:530*235*200mm
(customizable) | Metalcase:560*235*200mm(customizable) | Metalcase:560*235*200mm
(customizable) |
| Case material | metal case or stainless steel case(customizable) |
| Terminal Type | Anderson interface / Positive and negative screw terminals (customizable) |
| Warranty | 5 years |
| Lifecycle | Deep cycle life 4000 times, life span is more than 7 years |
Advantages of LifePO4 compared with lead-acid batteries:
-Various kinds of green, non-toxic and non-polluting raw materials.
-Long lifespan (2000-8500 cycles, lead-acid is ~400).
-Lightweight-save 60% weight
-Charging speed increased by 6 times
-Reduce the total life cycle cost.
-No heavy metals or acids; environmentally friendly
-Maintenance-free.
-Internal BMS; higher reliability.
-No memory effect.
-Less affected by high temperature.
-Can be installed in any direction
FAQs:
Q: Are you manufacturer?
A: We are manufacturer, and we sincerely welcome you to visit our factory!
Q. Can I print my LOGO on it?
A: YES, LOGO/sticker/OEM/ODM welcomed
Q: Do you accept OEM/ODM?
A: Yes,it is available.We have OEM group to design battery case.
Thanks to send us your requirements to custom the batteries.
Q: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
Contact us for more informations!
